Expanded Art Museum Footprint

Footprint and model of the Expanded Art Museum
Floor Plan for the First Floor of the Expanded Art Museum
Floor Plan for the Second Floor of the Expanded Art Museum

*Sculptural Garden: This garden, between Fairchild Theater and the Kresge Art Center will be redesigned as an inviting space with plantings, accessible walkways, places to sit and art. It will feature sculpture from the museum’s collection including Fritz Bultman’s Coat of Male.

Expanded Art Museum Construction Phases

Phase One: 23,500 gross sq. ft. (includes 5,500 sq. ft. of renovated space)

• Exhibition space - 11,700 sq. ft.
• Exhibition support area - 1,450 sq. ft.
• Public Services - 4,660 sq. ft.
• Education - 1,600 sq. ft.
• Administration - 1,700 sq. ft.
• Operations - 3,800 sq. ft.

Phase Two: 18,050 gross sq. ft.

• Exhibition space - 11,000 sq. ft.
• Exhibition support area - 3,800 sq. ft.
• Public Services - 2,900 sq. ft.
• Administration - 350 sq. ft.
